Ubiquiti Dream Router 7 – UDR7-EU
Regular price
R 7,710.00
Regular price
Sale price
R 7,710.00
Tax included.
Shipping calculated at checkout.
Complete your setup
Loading recommendations...
Dream Router 7
Desktop 10G Cloud Gateway with integrated WiFi 7, PoE switch, microSD storage, and full UniFi application support.
Bring routing and network control into your installation. Check internet handoff, local port requirements and the supported management application when planning your network.
Key features
- WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
- Coverage Area: 160 m² (1,750 ft²)
- Default WAN Ports: (1) 10G SFP+ (1) 2.5 GbE RJ45
- 2.5 GbE RJ45: 4 (1 PoE) (2.5G/1G/100M/10M)
Specifications
| Model / SKU | UDR7-EU |
|---|---|
| WiFi Standard | 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) |
| Coverage Area | 160 m² (1,750 ft²) |
| Default WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 |
| 2.5 GbE RJ45 | 4 (1 PoE) (2.5G/1G/100M/10M) |
| 10G SFP+ | 1 (10G/1G) |
| Power Method | Universal AC input, 100–240V AC, 1.5A Max, 50/60 Hz |
| IDS/IPS Throughput | 2.3 Gbps |
| Dimensions | ⌀110 x 184.1 mm (⌀4.3 x 7.3") |
| Weight | 1.1 kg (2.4 lb) |
| Supported Voltage Range | 100–240V AC |
| Max. Power Consumption | 26W (Excluding PoE output) |
| Form Factor | Compact desktop |
| NVR Storage | Pre-installed 64GB microSD for NVR |
| Management | Ethernet Bluetooth |
| Enclosure Material | Polycarbonate |
| Throughput – 6 GHz | 5.7 Gbps |
| Throughput – 5 GHz | 4.3 Gbps |
| Throughput – 2.4 GHz | 688 Mbps |
| Antenna Gain – 6 GHz | 6 dBi |
| Antenna Gain – 5 GHz | 7 dBi |
| Antenna Gain – 2.4 GHz | 5 dBi |
| Voltage Range PoE Mode | 44-57V |
| Power Supply | AC/DC, Internal, 50W |
Installation and compatibility
Match your internet handoff and local network connections to the listed interfaces. Port link rates and inspected routing throughput describe different capabilities.
