Dream Machine Special Edition
10G Cloud Gateway with 100+ UniFi device / 1,000+ client support, 3.5 Gbps IPS routing, and built-in PoE switching.
Bring routing and network control into your installation. Check internet handoff, local port requirements and the supported management application when planning your network.
Key features
- Default WAN Ports: (1) 10G SFP+ (1) 2.5 GbE RJ45
- 1 GbE RJ45: 8 (1G/100M/10M)
- 2.5 GbE RJ45: 1 (2.5G/1G/100M/10M)
- 10G SFP+: 2 (10G/1G)
Specifications
| Model / SKU | UDM-SE-EU |
|---|---|
| Default WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 |
| 1 GbE RJ45 | 8 (1G/100M/10M) |
| 2.5 GbE RJ45 | 1 (2.5G/1G/100M/10M) |
| 10G SFP+ | 2 (10G/1G) |
| Power Method | (1) Universal AC input, 100–240V AC, 4.4A Max., 50/60 Hz (1) USP-RPS DC input, 52V DC, 3.94A |
| IDS/IPS Throughput | 3.5 Gbps |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight | 5 kg (10.9 lb) |
| Supported Voltage Range | 100–240V AC |
| Max. Power Consumption | 50W (Excluding PoE Output) |
| Form Factor | Rack mount (1U) |
| NVR Storage | (1) 3.5" NVR HDD bay Built-in 128 GB SSD for Faster Experience |
| Management | Ethernet Bluetooth |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Voltage Range PoE Mode | PoE: 44-57V PoE+: 50-57V |
| Power Supply | AC/DC, internal, 240W |
Installation and compatibility
Match your internet handoff and local network connections to the listed interfaces. Port link rates and inspected routing throughput describe different capabilities.
