10G Cloud Gateway with 100+ UniFi device / 1,000+ client support and 3.5 Gbps IPS routing.
Bring routing and network control into your installation. Check internet handoff, local port requirements and the supported management application when planning your network.
Key features
Default WAN Ports: (1) 10G SFP+ (1) GbE RJ45
1 GbE RJ45: 9 (1G/100M/10M)
10G SFP+: 2 (10G/1G)
Power Method: (1) Universal AC input, 100–240V AC, 50/60 Hz (1) USP-RPS DC input
Specifications
Model / SKU
UDM-PRO-EU
Default WAN Ports
(1) 10G SFP+ (1) GbE RJ45
1 GbE RJ45
9 (1G/100M/10M)
10G SFP+
2 (10G/1G)
Power Method
(1) Universal AC input, 100–240V AC, 50/60 Hz (1) USP-RPS DC input
IDS/IPS Throughput
3.5 Gbps
Dimensions
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
Weight
3.9 kg (8.6 lb)
Supported Voltage Range
100–240V AC
Max. Power Consumption
33W
Form Factor
Rack mount (1U)
NVR Storage
(1) 3.5" NVR HDD bay
Management
Ethernet Bluetooth
Enclosure Material
Aluminium CNC, SGCC steel
Power Supply
AC/DC, internal, 50W
Installation and compatibility
Match your internet handoff and local network connections to the listed interfaces. Port link rates and inspected routing throughput describe different capabilities.
