Ubiquiti UniFi FlexHD Wi-Fi Access Point – Dual-Band 4x4 MU-MIMO Compact AP with Flexible Mounting

Ubiquiti UniFi FlexHD Indoor/Outdoor WiFi 5 Access Point

The Ubiquiti UniFi FlexHD is a compact indoor and outdoor WiFi 5 access point designed for flexible wireless deployments in homes, offices, businesses and mesh networks. Its discreet cylindrical design can be installed on a tabletop, wall, pole or ceiling, making it suitable for environments where conventional ceiling-mounted access points are not ideal.

Dual-band wireless connectivity combines a 4×4 MU-MIMO 5GHz radio with a 2×2 MIMO 2.4GHz radio, delivering maximum data rates of up to 1.733Gbps on 5GHz and 300Mbps on 2.4GHz. Wireless meshing provides additional flexibility when expanding UniFi coverage across a property.

The FlexHD connects through a Gigabit Ethernet port and supports 802.3af PoE, allowing network connectivity and power to be delivered over a single Ethernet cable. It is suitable for indoor and outdoor deployment and is weatherproof when correctly installed LED-side up using the appropriate included outdoor mounting hardware.

Specifications

• Brand: Ubiquiti
• Series: UniFi
• Model: UAP-FlexHD
• SKU: UAP-FLEXHD-EU
• Product Type: Indoor/Outdoor Wireless Access Point
• WiFi Standard: WiFi 5 / IEEE 802.11ac Wave 2
• Frequency Bands: 2.4GHz & 5GHz
• 5GHz MIMO: 4×4 MU-MIMO
• 2.4GHz MIMO: 2×2 MIMO
• Maximum 5GHz Data Rate: 1733Mbps
• Maximum 2.4GHz Data Rate: 300Mbps
• Networking Interface: 1 × 10/100/1000Mbps Gigabit Ethernet
• Power Method: 802.3af PoE
• Supported Voltage: 44–57V DC
• Maximum Power Consumption: 10.5W
• Antenna Gain: 1.6dBi at 2.4GHz / 4dBi at 5GHz
• Wireless Meshing: Supported
• Mounting: Tabletop, Wall, Pole or Ceiling
• Dimensions: Ø48.5 × 159.49mm
• Weight: 315g
• Operating Temperature: -30°C to 70°C
• Operating Humidity: 5% to 95% Non-Condensing
• Management: UniFi Network
• Colour: White

What's in the Box

• 1 × Ubiquiti UniFi FlexHD Access Point
• 1 × Base Mount
• 1 × Outdoor Mount
• 1 × Wall/Pole Mount
• 2 × Plastic Ties
• 1 × 48V 0.32A Gigabit PoE Adapter
• 1 × Power Cord
• Mounting Hardware
