1000W PCIE5.0 PSU

Ultra-High Performance PSU for Next-Gen PCs

The MicroWorld 1000W PCIe 5.0 Power Supply delivers stable, efficient power for high-end gaming PCs, workstations, and content creation rigs. Designed with ATX 3.0 & Intel PSDG compliance, it features a native 12VHPWR connector to support next-gen GPUs like NVIDIA RTX 40 Series and AMD RX 7000.

Key Features:

✔ PCIe 5.0 Ready – Supports 12VHPWR (600W single-cable power for high-end GPUs)
✔ 80+ Gold Certified – 90%+ efficiency under typical loads
✔ Fully Modular Cables – Customize wiring for optimal airflow & clean builds
✔ Silent 135mm FDB Fan – Zero RPM mode under low loads (<30% capacity)
✔ Premium Components – 105°C Japanese capacitors for durability
✔ Multi-Protection – OVP/UVP/OCP/SCP/OPP safeguards
✔ Compact ATX Size – Fits standard cases (150x140x86mm)

Technical Specifications:

• Wattage: 1000W

• Certification: 80+ Gold, ATX 3.0, PCIe 5.0

• Connectors:

  • 1x 12VHPWR (16-pin, 600W)

  • 6x PCIe 8-pin (6+2)

  • 2x CPU 8-pin (4+4)

  • 6x SATA, 4x Molex

• Fan: 135mm Fluid Dynamic Bearing (Silent mode <20dB)

• Input Voltage: 100-240V (Universal AC)

• MTBF: 100,000+ hours

Compatibility:

• GPUs: NVIDIA RTX 4090/4080/4070 Ti, AMD RX 7900 XTX/XT

• Motherboards: ATX, Micro-ATX, Mini-ITX

• OS Support: Windows & Linux

Package Includes:

• MicroWorld 1000W PSU

• Fully modular cables (including 12VHPWR)

• Mounting screws

• Quick installation guide

Ideal For:

• 4K/8K Gaming Rigs

• AI/3D Rendering Workstations

• High-End Overclocking Builds

Why Choose MicroWorld?

✅ Future-Proof Design – Ready for next-gen hardware
✅ Whisper-Quiet Operation – Fanless mode at low loads
✅ Reliable Power Delivery – Stable voltage for sensitive components
✅ Clean Cable Management – Fully modular for easy builds
